STEELFIX REGULAR
IDEAL FOR: facades. The channels permanently protect buildings from standing or pressurised water.
THE PRODUCT BENEFITS
ONE PRODUCT RANGE FOR ALL INSTALLATION SITUATIONS
= Performance assured | Design Flexibility
ONE PRODUCT RANGE FOR ALL INSTALLATION SITUATIONS
- four width: 115 mm, 155 mm, 205 mm, 255 mm
- four heights: 45 mm, 75 mm, 100 mm and 150 mm
= Performance assured | Design Flexibility
NUMEROUS GRATING OPTIONS
- made of recycled composite, galvanised steel, stainless steel
- asthetic mesh and longitudinal gratings
customised gratings available
= Design Flexibility
THE SYSTEM IN DETAIL
grating variants for STEELFIX sump unit, e.g. slotted grating, mesh grating, longitudinal grating, pavable inner trough
Screw socket
STEELFIX sump unit made of galvanised or stainless steel, for connection installations in concealed reveal areas
Various grating options, for example slotted grating, mesh grating, perforated grating and longitudinal grating, in these materials: recycled composite, galvanized steel, stainless steel
Locking system for easy connection of channel unit or optional screw fastening of grating, upgradeable at any time
channel made of galvanised or stainless steel, various widths, with fixed construction height
concrete anchor
Antifloating
screw socket with adaptor and double socket
channel as drain element with various connection possibilities
End cap for channel opening and end with clip-function for secure locking
end cap for cross-intersection channel
cross-intersection channel as closed variant
screw socket with adaptor
KG sheet
